Designation

Detection and identification of multicopters and tracking their movement on a map by analyzing radio signals emitted by multicopters.

Composition

— “Dronoscope” — UAV detector (quantity in accordance with the Complex tasks);
— “Dronoscope-DF” — UAV detector/direction-finder (quantity in accordance with the Complex tasks).

Capabilities

— automatic detection, decoding of the type, serial number, the coordinates (of the multicopter, operator’s console, the take-off point) of DJI multicopters (with unmodified software) and multicopters with Remote ID;
— automatic detection of Autel, DJI, FIMI, FPV multicopters digital and analog video), fixed-wing UAVs for which a neural net has been trained;
— interception of signals of FPV-multicopter on-board analog video transmitters;
— automatic detection of multicopters with control systems based on Wi-Fi protocols;
— audio alerting the operator on detection of a UAV;
— UAV direction-finding and positioning with display on a terrain map.

Specifications

Parameters	Value
Operating frequency range	400–9000 MHz
Types of detected multicopters	Autel, DJI, FIMI, FPV, Wi-Fi, fixed-wing UAVs (once a neural network has been trained)
Location	DJI, Remote ID
Detection range:
DJI	up to 4 km
Autel, FPV, FIMI	up to 3 km
Wi-Fi, Remote ID	up to 1 km
Distance from the signal processing unit to the operator's computer	up to 50 m
Power supply	network 220 V 50 Hz; from a battery (portable power unit)
Weight (without computer)	max 12 kg
